Hydraulic Photovoltaic Pile Driver

PRODUCT  DESCRIPTION


The hydraulic hammer pile driver is a new type of pile driver that uses diesel belt starter and oil pressure as its power. It can adjust the hydraulic pressure according to the different soil types to achieve the appropriate impact force for piling. Small and medium-sized hydraulic pile drivers are often used for piling highway guardrails and highway guardrail construction. The energy transfer efficiency of the hydraulic hammer pile driver can reach 70%~95%. The hydraulic hammer pile driver has precise piling control and can achieve piling operations in different strata. The hydraulic hammer pile driver has excellent performance in reducing noise, vibration and noise, and is particularly suitable for urban construction needs. The hydraulic hammer pile driver has obvious energy-saving and emission-reduction effects and is the mainstream of future pile driver development .


Machine size4700*2100*2800mmTrack shoe width400mm
engineFour-cylinder diesel engineDrilling diameter80-400mm
Drilling depth0-6m (can be connected to a pole)Reducer torque13000N.m
Mainstream pumpsTriple PumpOil Pump40/40/32
Drill pipe speed180r/minClimbing angle30°
Slide pitch angle120°Drill arm swing angleLeft and right 15°
Rock hardness6-20FWalking speed0-3km/h
Machine weight6.5T
