Product application scope
Aerial work platform trucks are widely used in electricity, street lights, municipal administration, gardening, communications, airports, shipbuilding (repair), transportation, advertising, photography, and other aerial work fields.
| model | XRMG60M |
| Chassis model | QL1251FTFZY | Chassis brand | ISUZU |
| Wheelbase | 5100+ 1370mm | Engine Model | 6HK1-TCG60 |
| Engine power/displacement | 221KW/7790ml | Tire model | 295/80R22.5 18PR |
| Maximum working height | 60M | Vehicle size | 10780*2550*3990mm |
| Maximum working range | 45M | Total mass | 25000kg |
| Working height at maximum working range | 51M | Cylinder | Xuzhou Yanhuang |
| Working range at maximum working height | 2.1M | Outrigger span | 7890/7980mm |
| Boom type | 10-section boom synchronous extension and retraction | Outrigger structure | Three-leg X-type |
| Arm material | Baosteel 960 | Boom heave angle | -10/+75° |
| Boom structure | 18 arm | Hydraulic lock | Yangzhou Zhongmei Hydraulic YS6-03H |
| Basket size | 3200*700*1000mm | Nylon Sliders | (Xuzhou Black and White Dragon) |
| Hydraulic reel | Shanghai Quantuo | Electronic control system | Hunan Cyber remote control distance 150 meters |
| On-board valve | Beijing Shengweihua (joint venture) TPSL3-DSE12-04-X2-01 | How it works | Electric control, remote control |
| Leveling form | Static automatic | Leveling device | Hydraulic oil pipe leveling |
| Turntable rotation form | 360° | Slewing support | Jiangsu Changzhou Kesen S19-116-LH-250A-REVA |
| Rotation form | 360° | Working platform rated | 600KG within 45 m, 400KG above 45 m |
| Arm form | Taiwan leaf chain | Back arm form | Taiwan leaf chain |
| Standard Configuration | Cab, air conditioning, weighing, wind speed sensor |
