Concrete Mixing Plant DHZS Series

Product Introduction


DHZS series bucket-lift concrete mixing station is developed by our company's engineering and technical personnel by combining the advantages and advanced technologies of various domestic and foreign models and the company's many years of experience in producing concrete mixing equipment.

DHZS series bucket-lift concrete mixing station adheres to our company's innovative design concept and provides great convenience for concrete production enterprises. Welcome to buy!

Product features

★ The floor space can be saved by nearly half compared with the inclined belt conveyor feeding.

★ The installation and commissioning time of the whole set of equipment will save about 40% compared with the conventional station.

★ The mixing, metering platform and lifting system platform have the same space as the conventional mixing station, which fully guarantees the needs of calibration, inspection and maintenance.

★ When full closure is required, it can still meet the working space requirements.

★ The DHZS series uses imported motors and reducers as the lifting body.

★ The unique design of the hopper and track can more efficiently hold and dump aggregates.

★ Through the optimized combination, the feeding-mixing-discharging cycle is shortened, and the production capacity is effectively improved.


nameThrough-putcapacityProductivityMaximum aggergate sizePowerMixing motorpowerLiftingmotorpower  Hoisting speed of bucket
unitLm³/hmmkwkwkwm/s
DHZS90240090801602x30221.1
DHZS1203200120802002x37371.1
DHZS1804500180≤802352x55451.1
