Concrete Mixing Plant JS750

Product Introduction


Concrete mixing station is mainly composed of five systems including mixing host, material weighing system, material conveying system, material storage system and control system and other ancillary facilities. Compared with the aggregate measurement of the station, the aggregate measurement of the floor reduces four intermediate links, and the material measurement is vertical, which saves the measurement time and greatly improves the production efficiency.


ltemJS750
Theoretical capacity70m³/h
Model of mixerJS750
Mixing motor power2x30kw
Number of kinds of aggregate4
Discharge height3.8m
Maximum weighing value of cement2000kg
Maximum weighing value of coal ash1200kg
Maximum weighing value of water500kg
Maximum weighing value of additive  50kg
Overall dimension(LxWxH)11764x6080x7866mm
