Brand

Tangjun

Volume

2.6m³

Engine model

Yunne 4100

Oil type

diesel fuel

Engine power

52kW

Cab

single row

Drive form

4X2

Steering Type

steering wheel

Number of axes

2

Steering assistance

Hydraulic boost

Wheelbase

2650

Clutch boost

Air assist

Service brake

exhaust brake

Number of leaf springs

forward 9,back 9+5

Parking brake

air brake

Fuel tank volume

70L

Gearbox

WLY10H35

Battery

2-12V-60AH

Shift method

manual operation

Tank and blade material

Q345B-4mm

Gear

5- forward gear,1- reverse gear,High and low speed

Vessel head

Q345B-6mm

Top speed

60km/h

Hydraulic system

Open hydraulic system

Rear axle specification

1066

Reduction box

KEYI

Tire specifications

7.50-16LT

Hydraulic valve

15 single

Number of tires

6

Feed rate

≥3m³/min

Gradeability

25°

Outlet speed

≥1m³/min

Discharge height

1200mm

Discharge residual rate

≤0.5%

Tank volume

4.2m³

Unloading range

180° Rotary discharge

Max. stirring volume

2.6m³

In and out operation

post operation

Min. turning radius

4.5m

Tank rotation speed

12rpm

Net weight

3820kg

Tank volume

180L

Gross weight

10500kg

Hydraulic radiator

18L Temperature-controlled automatic control aluminum exchanger

Whole Dimention

5500x2050x2700mm

Rated hydraulic pressure

20MPa

Optional configuration

Air conditioner, increase the feeding hopper, support mixing dry materials, install anti-leakage hopper, operate in and out of the material, construction machinery license and insurance, etc.
